Freedeo 3D System

Product introduction

Timewaying is a professional cinema equipment manufacturer that integrates research and development, production, and sales of 3D cinema equipment and peripheral products. Freedeo 3D system is used by over 6500 cinemas, boasting more than 28000 installations globally.

FD-S20

A highly integrated design facilitates quick and convenient installation and maintenance.
Through a high-temperature vacuum, a layer of tight molecular film is formed on the glass surface. The film can resist most oil stains, which makes cleaning and maintenance a breeze.

FD-T03D

Highly integrated design, easy to installation and maintenance.
Produces a frame rate of 120fps or above and a responsetime of less than 150 μs, making frames smooth.
Polarized beam splitter(PBS) produces ultra clear pictures with excellent coincidence.

FD-T05P

The transmittance increased to 74% and light efficiency to 29%, even single projector can support a big screen.
By adopting unique contrast-enhanced technology, the contrast rate reaches up to 500: 1 or above which bring you amazing 3D stereoscopic images.
Applicable to the projection ratio of 0.95:1 above the theater, the minimum projection distance of 10 meters. At the same time, the screening window requirements are reduced, compatible with most of the movie hall.

FD-T05L

The transmittance increased to 76% and light efficiency to 30%, even single projector can support a big screen.
By adopting unique contrast-enhanced technology, the contrast rate reaches up to 500: 1 or above which bring you amazing 3D stereoscopic images.
Applicable to the projection ratio of 1.25:1 above the theater, the minimum projection
distance of 8 meters. At the same time, the screening window requirements are reduced,
compatible with most of the movie hall

Specification

ModelFD-S20FD-T03DFD-T05PFD-T05L
ItemSpecificationParametersParametersParametersParameters
Turbo ScreenPolarizer Dimensions216L*195W*22H mm502L*211W*413H mm364L*427W*116H mm345L*110W*336H mm
Optical PrincipleCircular PolarizationCircular PolarizationCircular PolarizationCircular Polarization
Light Transmittance42%±172%±174%±176%±1
Light Effciency16%±128%±129%±130%±1
Contrast Ratio> 300:1> 300:1> 500:1> 500:1
Ghosting Rate< 0.5%< 1%< 0.5%< 0.5%
Supported Frame Rate24/48/60/120 fps24/48/60/120 fps24/48/60/120 fps24/48/60/120 fps
2D/3D Intelligent Switchover (TMS)Available
One-click Transposition of Left and Right PictureAvailable
Silver ScreenGain> 2.4
Polarization Contrast> 150:1
Digital ProjectorXenon lamp projector:SupportAvailable
RGB Laser projector:SupportAvailable0.69″ DMD Clip Available/Available
ALPD Laser projector:SupportAvailable
Projection HallThrow Ratio/1.25 : 1 or aboveMinimum:0.95 : 11.25 : 1 and above
Distance/10~30 m10~35 m8~32 m
Installation requirementsProjection window/window requirements 500*500mmwindow requirements 600*600mm
